Infusion Pumps
SO-CONNECT Ambulatory Infusion Pump
Designed to meet the highest standards in the ambulatory pump market, the SO-CONNECT sets a new benchmark in subcutaneous immunoglobulin (SCIg) infusion therapy. Fully licensed for SCIg infusion and Desferal administration, this pump is the ultimate solution for both clinical and home-based care.
Built for Both Patients and Professionals
Whether in a clinical environment or at home, the SO-CONNECT simplifies infusion management. The SO-CONNECT empowers healthcare professionals and patients alike with reliable, safe, and smart infusion management.
Key Features
-
Compatibility: Supports 20, 30, 50, and 100 mL syringes with a standard Luer-lok connection. Compatibility with all Luer-lok infusion sets ensures flexibility in your choice of accessories.
-
Comprehensive Safety: Includes syringe detection, advanced occlusion detection, alarms, and a display lock to prevent unauthorized changes.
-
Flexible Titration: Customizable with 5 adjustable infusion levels for tailored treatment.
-
Smart Data Management: Bluetooth-enabled for seamless transmission of clinical data and full data retention for analysis.
-
User-Friendly Design: Features a 2.4” touchscreen for intuitive operation.
SO-CONNECT®
Feature | Details |
|---|---|
Pump Dimensions / Weight | 78 x 72 x 40mm, 200g (including battery) |
Battery / Battery Life | Rechargeable VARTA Pack XL (3.7V; 2400mAh; 8.9 Wh) 10 Infusions (In standard use) |
Programmable volume | 1ml to 600ml (in increments of 1ml) with a guided syringe change feature |
Dedicated single use syringes | 20ml, 30ml, 50ml & 100ml (Adaptor required for 100ml syringe) |
Configuration | Mono or multi-flowrate, configuration of up to 5 steps |
Infusion rates | 0.1ml to 300ml/h |
Programming mode | Set either the flow-rate or duration (the pump calculates the other parameter) |
Precision of infusion | +/- 5% |
Occlusion pressure | 5 bars |
Post-occlusion bolus | 1.1ml |
Memory | All the parameters are saved, even when the battery is removed |
Security | Password required to change infusion parameters |
Safety Features | Comprehensive alarm system compliant with regulations, switch to detect the syringe |
Optimised occusion detection algorithm | Acoustic ranges of alarms, 44dB(A) for high priority alarms, 38 dB(A) for low priority alarms |
Screen | Resistive touchscreen: TFT 2,4” RGB 320 x 240 pixels |
Motor | Stepper motor with magnetic encoder |
Degree of protection | IPX2 |
Supplied accessories in box | Battery charger, 2 batteries, user manual, stylus |
Warranty | Two years against manufacturing defects |
